Petal Tower — Zaha Hadid fluid biomorphic

Four colliding deconstructivist volumes — each from a different master

Petal Tower — Zaha Hadid fluid biomorphic (58 m / 14 storeys) Every floor is a different size and rotation. The cross-section uses twist_angle() based on sin²(πz/2H) — slow start, rapid mid-rise, ease into crown — giving the authentic Hadid fluid twist from 0° at grade to 42° at the top. The ellipse axes breathe with petal_offset() = A·sin(3πz/H) and A·cos(2πz/H) — pinching at mid-height then opening back out. Eight vertical bronze structural fins spiral with the building. Diagonal glazing slashes cut through the titanium skin at every other floor. White GRC organic crown with glazed cap.

Shard Volume — Frank Gehry fragmented crystalline (44 m / 10 storeys) Six interpenetrating angled volumes, each at a different tilt from the Fibonacci-derived array [8°, 15°, 18°, 22°, 11°, 26°] — no two facets share the same angle. The whole mass leans 8° south-east (aggressive Gehry cantilever gesture). Diagonal glazing slashes per facet. Four skylights cut through the zinc-clad roof. A double-height all-glass atrium at the base with angled glazing on both axes.

Ribbon Wing — Hadid horizontal parametric (120 m long) Sixteen segments, each evaluated with ribbon_section_w(t) = w₀(1−t) + w₁t + A·sin(πt) — the cross-section morphs from a 14 m oval at the west end to a 4 m blade edge at the east. The lean is A·sin²(πt), pushing the ribbon south as it narrows. White GRC west, titanium east, switching at 45% of the length. Vertical oak louvre brise-soleil on the south face. Continuous glazing strips on both south and north. 12 m cantilevered nose at the east end tilted down 6°. The soffit is an exposed white GRC plane visible from the plaza.

Void Cube — Daniel Libeskind angular void (8 × 8 × 14 m) Positioned where it cuts into the ribbon wing — creating compression and absence. Four zinc walls each at compound angles, all slightly different rotations. An angled skylight cuts the top at 18°/12°/22° compound angle. The base is a polished basalt memorial garden with cool blue light emanating from it — the Libeskind memorial quality. Starts dark at dawn, slowly activates through the reveal act.

Materials — 9 custom node-built shaders: Titanium with press-brake Wave fold lines + anisotropic brush; Brushed Stainless with horizontal grain + Fresnel rim; Zinc with 4-stop blue-grey patina ramp + streak variation; Low-iron structural glass with slight green tint; White GRC with micro-SSS; Polished black basalt with Voronoi crystal sparkle; Dark board-form concrete; Cast bronze with green patina overlay; and Warm oak louvre with Wave ring grain.
